Detail produk:
|
| Merek: | ZOOMLION | Merek sasis: | Mercedes Benz Actros 4141 |
|---|---|---|---|
| Model: | ZLJ5440THBK 56X-6RZ | Standar emisi: | Euro3/11.946L |
| Torsi maks (N·m/rpm): | 2000/1080 | GVW (KG): | 43171 |
| Dimensi Keseluruhan (mm): | 13877×2500×3966 | Jangkauan Vertikal: | 56m/6 bagian |
| Tekanan (Tekanan Rendah/Tinggi): | 8.3/12Mpa | ||
| Cahaya Tinggi: | Truk Pompa Beton 56m,Truk Pompa Beton Zoomlion,Zoomlion 56X-6RZ |
||
| Merek | Zoomlion | |
| Merek Sasis | Mercedes Benz Actros 4141 | |
| Model | ZLJ5440THBK 56X-6RZ | |
| Tanggal rilis | 2013 | |
| Casis | Kabin | Actros 4141 |
| Modus mengemudi | 8*4 | |
| Model mesin | OM501LA.III/17 | |
| Standar emisi | Euro3/11.946L | |
| Daya keluaran maksimum (Kw/rpm) | 300/1800 | |
| Torsi maks (N·m/rpm) | 2000/1080 | |
| Model transmisi | RTLO16918B 18 maju 4 terbalik |
|
| Gandar belakang: rasio/kapasitas pemuatan | Batang V Kiri Belakang/23,4 ton | |
| Sistem pengereman | Udara penuh, sirkuit ganda | |
| Jarak sumbu roda (mm) | 2020+4280+1350 | |
| Ban | 315/80R22.5 | |
| GVW (Kg) | 43171 | |
| Dimensi keseluruhan (mm) | 13877×2500×3966 | |
| Sistem Boom & Pompa | Jangkauan vertikal | 56m/6 bagian |
| Ukuran pipa | 125mm | |
| Selang Akhir (L * D) | 3000*125mm | |
| Keluaran (Tekanan Rendah/Tinggi) | 180/120m³/jam | |
| Tekanan (Tekanan Rendah/Tinggi) | 8.3/12Mpa | |
